B&G Zeus SR Multifunction Display with C-MAP Discover X - 12" - 000-16024-001

Elevate your instincts with the Zeus SR chartplotter. B&G's most powerful 8-core processor delivers a smoother, faster sailing experience. Redesigned interface makes it easier to find the tools you need, with tailored screens for cruising, racing, and anchoring. And a whole host of control options gives full power to the helm in all conditions.

Features:

• High definition SolarMAX IPS touchscreen, viewable from all angles, even with polarised glasses
• Separate modes for Cruising, Racing and Anchoring
• Award-winning sailing features like SailSteer, LayLines, Routes and StartLine
• Compatible with C-MAP DISCOVER X and REVEAL X charts
• C-MAP-powered Safety Alerts
• Full integration with HALO radars, B&G Sailing Processors, Autopilots, Triton 2 and Nemesis instruments, wind sensors and more
• B&G App integration with 12 months premium subscription when registering a C-MAP X Chart
• Wi-Fi 5, Gigabit Ethernet and NMEA 2000 networking
• Supports up to four IP video cameras
• C-MAP X-Gen charts deliver the cutting-edge of navigation
• Explore the stunning DISCOVER X charts, zooming in and out in an instant
• Discover new spots with incredible local detail
• Explore after dark with a dedicated night mode
• The X-Gen charts also unlock a host of ground-breaking features, such as the revolutionary C-MAP Safety Alerts
• Built to automatically alert boaters to hazards up ahead, from shallow waters to buoys
• In an industry first, the X-Chart Manager lets users manage C-MAP chart updates and upgrades directly from the device, with the ability to choose custom areas for a near-instant download
• X-Gen charts are always evolving, adding new details and features all the time
• B&G's latest OS has integration at its core, with seamless networking across the entire boat
• Connect to HALO radars for superior safety and situational awareness
• Unlock next-level performance with the Triton Edge and Hercules sailing processors
• Compatible with wind sensors, which feed into B&G's range of Triton and Nemesis instruments

Specifications:

• Resolution: 1280 x 800
• Brightness: >1200 nits
• Touchscreen: Full touchscreen (multi-touch)
• Viewing angles in degrees (typical value at contrast ratio = 10): 80 deg. top/bottom, 80 deg. left/right
• Supply voltage: 12/24V DC (10 - 31.2V DC min - max)
• Dimensions (W x H x D): 13.34" x 8.20" x 3.34" (338.9 mm x 208.4 mm x 84.8 mm)
• Recommended fuse rating: 5A
• Maximum power consumption: 28W
• Protection: Reverse polarity and over-voltage (max 32V)
• Operating temperature: 5°F to 131°F (-15°C to 55°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
• Waterproof rating: IPX6 and IPX7
• Shock and vibration: 100,000 cycles of 20 G
• GPS: 10 Hz GNSS receiver for GPS and GLONASS, supports combinations with Galileo, Beidou, QZSS. SBAS (WAAS)
• Wi-Fi: Wi-Fi 5 (IEEE 802.11ax)
• Ethernet: 1 port (X-Coded M12 GbE)
• Echosounder: No internal Echosounder. Compatible network echosounder required if needed
• NMEA 2000: 1 port (Micro-C connector)
• Data card slot: 2x (microSD, SDHC)
• USB: Not applicable
• HDMI: 1 port (video input)
