Fireboy 2 Channel Gasoline Fume Detector with Blower Control

The Fireboy 2 Channel Gasoline Fume Detector monitors gasoline vapors with dual sensors and includes automatic blower control for enhanced safety. It is designed to detect leaks early and activate ventilation systems to reduce fume buildup.

Features:

• Dual-channel detection with two sensors for comprehensive monitoring of gasoline fumes
• Automatic blower activation to ventilate enclosed spaces and reduce hazardous vapors
• Audible 68 dBA alarm and red LED indicator trigger at 20% of the lower explosive limit
• Wide voltage range supports 9V to 30V DC power input for versatile installation
• Reverse polarity protection ensures safe and reliable operation in various setups
• Compact design with a 2 5/8" bezel and simple round cutout for easy mounting
• Durable operation across extreme temperatures from -40°F to 185°F (-40°C to 85°C)

Specifications:

• Bezel Diameter: 2 5/8" (67 mm)
• Cutout Size: 2 1/8" (54 mm) Round
• Power Requirements: 9-30V DC
• Current Draw (12V DC): Nominal 95 mA, Maximum 150 mA
• Operating Temperature: -40°F to 185°F (-40°C to 85°C)

Included:

• (1) x 2-Channel Gasoline Detector with Blower Control
• (2) x Plastic Fuel Sensors
• (2) x 20' (6 m) Extension Cables
• (1) x 30A Relay (12V DC)
• (1) x User Manual
