Furuno NavNet TZtouchE Multifunction Touch Screen Display - 13" - TZT13E

The Furuno TZT13E is a multi-function display fishfinder and chartplotter designed for advanced navigation, sonar performance, and full system integration. Built on the TZtouchXL platform, it delivers intuitive multi-touch control and scalable functionality for vessels of any size.

The 13" display combines advanced charting, CHIRP fishfinding, and real-time system control in a larger format for improved visibility. Built-in TruEcho CHIRP, CHIRP Side-Scan, and TZ MAPS support provide detailed underwater imaging and highly customizable navigation data.

The intuitive TZtouchXL interface allows operation through simple taps and edge-swipe gestures, delivering fast access to navigation, radar, and sonar functions with minimal setup time.

Features:

• 13" multi-touch IPS display with TZtouchXL interface for intuitive control
• Built-in TruEcho CHIRP fish finder with 300W, 600W, or 1 kW output
• Integrated CHIRP Side-Scan for high-definition port and starboard imaging
• TZ MAPS support with satellite imagery, bathymetric overlays, and custom chart layers
• AI routing and dynamic navigation tools based on vessel draft and chart data
• Full radar compatibility including Furuno NXT solid-state Doppler radar systems
• Network integration with cameras, IP devices, and onboard sensors
• TZ Weather integration with global forecasting and advanced weather models
• Cloud synchronization for routes, waypoints, and system data via TZ Cloud
• Dynamic Mooring feature for evaluating safe anchorage based on forecast conditions
• Risk Visualizer and AI Avoidance Route for enhanced situational awareness

Specifications:

• Display Size: 13"
• Display Type: Color multi-touch LCD
• Sonar Frequency: CW 50 - 200kHz, CHIRP 40 - 225kHz
• Sonar Power Output: 300W, 600W, or 1 kW
• Sonar Range: 1,200 m (3,937')
• Power Input: 12 - 24V DC
• Chart Types Supported: CMOR, TZ MAPS

Data Sheet (2.99 MB)
