Harken Aluminum Element Block - 60 mm (2 3/8") - 6274

Harken Element™ Blocks introduce side plates that combine forged aluminum and compound curves for strength in a design that pairs the minimum amount of metal required to protect the sheave with a proven journal bearing.

Size for size, Element blocks are priced significantly lower than Harken's previously least expensive blocks.

Features:

• Side plates are hardcoat-anodized to resist corrosion
• Tough, composite bearing sheave resists corrosion for long service life

Specifications:

• Sheave Diameter: 2 3/8" (60 mm)
• Length: 5 3/4" (146 mm)
• Weight: 24.2 oz (690 g)
• Shackle pin Diameter: 5/16" (8 mm)
• Maximum line Diameter: 1/2" (12 mm)
• Maximum working load: 1499 lbs (680 kg)
• Breaking load: 2998 lbs (1360 kg)

Note: do not use Harken Equipment for human suspension.

Installation Guide
