Harken Protexit Wide Sheave Single Exit Block - 60 mm (2 3/8") - 1209

The Protexit Exit Block with Wide Sheave is designed for high-load halyard applications where side-angle loading and line wear are common. Its aluminum housing and wide sheave construction provide durability and smooth line handling in demanding sailing conditions.

Features:

• Wear-resistant aluminum housing helps reduce sideplate damage caused by side-angle loading
• Wide sheave design improves line guidance during repeated hoists and douses
• Aluminum sheave rotates on sleeve bearings with Delrin sideload balls for smooth operation under extreme conditions
• Helps reduce halyard wear while maintaining consistent performance under load
• Designed for higher working loads compared to traditional small boat exit blocks

Specifications:

• Dimensions (A x B): 39 x 84 mm (1 9/16" x 3 5/16")
• Fastener Spacing: 105 mm (4 1/8")
• Sheave Diameter: 60 mm (2 3/8")
• Length: 129 mm (5 1/16")
• Weight: 296 g (10.4 oz)
• Maximum Line Diameter: 12 mm (1/2")
• Fastener Size: FH 6 mm (1/4")
• Maximum Working Load: 1200 kg (2640 lbs)
• Breaking Load: 2400 kg (5292 lbs)
