Hella Marine EuroLED Touch 150 Downlight with Switch/Dimming

The Hella marine EuroLED® Touch 150 Downlight provides ultra reliable, power-saving illumination for a wide range of commercial and recreational applications. It is a recessed, dual-color (red / white) light with touch-sensitive switching and dimming. For greater convenience the light can also be remotely operated from multiple points with On / Off / On momentary switches.

Features:

• EuroLED Touch technology provides ultra reliable, power-saving illumination for a wide range of commercial and recreational applications
• Completely sealed recess-mount LED lamp unit is highly impact and shock resistant for an ultra-long service life
• Advanced Hella marine lens technology provides safe, smooth and uniform light pattern without glare or discomfort
• Dual-color lamp with touch-sensitive switching and dimming
• Touch color pad for On / Off control, hold finger on pad to cycle through dimming levels
  • Touch red pad for red light, white pad for white light
  • Press pad for more than two seconds and lamp will cycle through increasing / decreasing intensity levels until maximum / minimum intensity is reached release your finger on the light level required
• Light levels are stored by lamp circuitry, even when vessel's batteries are turned off
• Lamp can also be remotely operated from multiple points with On / Off / On momentary switches
• Integrated Multivolt™ electronics provide consistent illumination and protection across a range of input voltages from 9-33 DC, even under severe voltage fluctuations, low battery voltages and long cable runs
• White surface-mount spacer included with lamp

Specifications:

• LED Color: Warm White (3000 K) / red
• Mount: Recessed
• Bezel (rim): Polished stainless steel
• Lens: UV resistant enhanced-impact acrylic
• Operating Voltage: 9 - 33V DC
• Power Consumption: 4.0W
• Current Draw: 0.33 Amp @ 12V DC / 0.16 Amp @ 24V DC
• Cutout: 4.88" dia. x 0.79"
• Bezel (rim): 5.90" dia
• Ingress Protection: IP 67 (Dustproof / protected against temporary immersion to depth of 1 m)
• Approvals: CE
