KICKER PXA Waterproof Amplifier

The PXA Waterproof Amplifiers are designed for rugged use. These amplifiers feature fully sealed construction with IP66 and IP67 ratings, ensuring reliable performance in wet and dusty conditions.

Features:

• Constructed with sealed bulkhead grommets and gasketed joints to prevent water and dust intrusion during harsh weather conditions
• Equipped with shielded in-line power and ground couplers that allow easy, solder-free cable extensions for flexible installation
• Offers a sealed preamp control door to protect internal components while maintaining user access
• Compatible with remote bass level control for on-the-fly audio customization
• Built with a rugged enclosure that withstands exposure to heavy water jets and submersion up to 1 m (3')
• High-efficiency Class-D technology
• Dual turn-on modes (choice of DC offset or 12V trigger)
• Includes stainless-steel mounting hardware and inline power and ground couplers that need no soldering or crimping

Specifications:

• 300W Model:
  • Model Number: PXA300.1
  • Channels: 1
  • Power:
    • 1 ohm Mono: 300W x 1
    • 2 ohm Mono: 250W x 1
    • 4 ohm Mono: 150W x 1
  • Dynamic Power: 500W
  • Frequency Response: 25 - 200Hz (+0/-3 dB)
  • Dimensions (W x H x L): 4 1/2" x 1 7/8" x 9 3/4" (114.7 x 47 x 247.5 mm)
  • CXARC Remote Capable: Yes (sold separately)
• 400W Model:
  • Model Number: PXA400.4
  • Channels: 4
  • Power:
    • 2 ohm Stereo: 150W x 4
    • 4 ohm Stereo: 100W x 4
    • 4 ohm Mono: 300W x 2
  • Dynamic Power: 800W
  • Frequency Response: 10Hz - 20 kHz (+0/-3 dB)
  • Dimensions (W x H x L): 4 1/2" x 1 3/4" x 9 3/4" (114.7 x 45 x 247.5 mm)
  • CXARC Remote Capable: Yes (sold separately) low pass mode only)
• 600W Model:
  • Model Number: PXA600.1
  • Channels: 1
  • Power:
    • 1 ohm Mono: 600W x 1
    • 2 ohm Mono: 500W x 1
    • 4 ohm Mono: 300W x 1
  • Dynamic Power: 850W
  • Frequency Response: 25 - 200Hz (+0/-3 dB)
  • Dimensions (W x H x L): 4 1/2" x 1 7/8" x 9 3/4" (114.7 x 47 x 247.5 mm)
  • CXARC Remote Capable: Yes (sold separately)
• 1000W Model:
  • Model Number: PXA1000.5
  • Channels: 4
  • Power:
    • 2 ohm Stereo: 150W x 4
    • 4 ohm Stereo: 100W x 4
    • 1 ohm Mono: 600W x 1
    • 2 ohm Mono: 500W x 1
    • 4 ohm Bridged Mono: 300W x 2 (Amp 1 and 2), 300W x 1 (Sub Channel)
  • Dynamic Power: 1400W
  • Frequency Response: 10Hz - 20 kHz (+0/-3 dB)
  • Dimensions (W x H x L): 4 1/2" x 1 15/16" x 12 7/8" (114.7 x 50 x 327.5 mm)
  • CXARC Remote Capable: Yes (sold separately) sub channel only)

Included:

• (1) x Waterproof IP66/IP67 power sports amplifier
• (2) x DC power couplers
• Stainless-steel mounting hardware
• (1) x Customer information card

Owner's Manual (26.44 MB)

Specfication Sheet (1.87 MB)
