Raritan PHII Manual Compact Marine Toilet

Features:

• Simple design of popular non-macerating manual toilet offers economical and trouble-free operation
• Double-action piston pump simultaneously draws new flush water in as it discharges wastewater
• Flexible installation for mounting above or below waterline
• Toilet is easy to clean and maintain - an excellent choice for sailboats and mid-size powerboats
• Supplied with "Slow Close" toilet seat and lid
• Retractable lever handle with intake water flush control valve
  • Lever handle pumping is more efficient, simpler and cleaner than competing vertical piston pumps
  • Simple 1/4 turn of control valve easily utilizes dry pump option
• Pump constructed of engineered polymer offers strength and durability superior to PVC
• Full-size joker valve reduces clogs and increases pump performance
• Each unit is assembled by hand and individually tested
• 1-year limited warranty

Specifications:

• Height: Compact marine
• Bowl Color: White
• Water Supply: Raw sea or lake water, hand operated double-action piston pump
• Flush Control: Retractable lever handle with intake water control valve
• Inlet Hose: 3/4" ID
• Discharge Hose: 1 1/2" ID

Note: Pump orientation is determined by the side the pump is on when facing the toilet from the front.

Installation and Maintenance Instructions

Product Brochure

Installation and Maintenance Instructions (2.72 MB)
