Ritchie Voyager Compass - F-83W

The Ritchie Voyager F-83W Bracket Mount Compass is designed for both power and sailboats. It is flush mounted, has a 3" CombiDamp dial that is illuminated and comes with a built-in sun shield.

Features:

• 3" CombiDamp dial
• Easily installed compass is adjustable and removable with bracket and thumbscrews
• Scientifically matched sapphire jewel and hardened steel pivot dial movement
• Powerful DirectiveForce magnets for fast heading lock-on
• Built-in compensators to easily adjust for deviation
• Exclusive built-in green NiteVu night illumination
• Movable sun shield
• High-temperature composite construction for extended operating range
• 100% repairable
• Exclusive 5-year Ritchie warranty

Specifications:

• Mounting Style: Flush mount
• Boat Type: Power or sail
• Apparent Dial Diameter: 3"
• Dial Design: CombiDial
• Compass Color: White
• Dial Color: White
• Night Lighting: 12V DC (green) standard

Installation, Compensation and Maintenance Instructions
