Item #1810355

Sierra 3-Position Magneto Ignition Switch - MP39100

$48.13
Want an email once available?

Image of : Sierra 3-Position Magneto Ignition Switch - MP39100 Sierra 3-Position Magneto Ignition Switch - MP39100 Item # 1810355

Description

Features:

  • Maximum corrosion protection - eliminates oxidation
  • Inner seal between cylinder lock and contact plate
  • Non-conductive housing eliminates potential shorts

Specifications:

  • Back Up Nut: Brass
  • Face Nut: Hex Black Plastic
  • Hole Size: 7/8"
  • 1 1/8" maximum panel thickness
  • Material: Marine grade glass-filled Polyester
  • Rated Ignition: 15A @ 12V DC
  • Rated Solenoid: 30A @ 12V DC
  • Terminal Type: 5 Screw Tab
  • Type: 3 Position Magneto
  • Switch Positions: Off - Run - Start

Replaces:

  • Johnson/Evinrude Outboard:
    • 0378238
    • 386545

Part Numbers for Sierra 3-Position Magneto Ignition Switch - MP39100
