Xantrex TRUECharge2 Battery Charger

The 2 bank Xantrex™ TrueCharge2 Battery Charger features efficient, power factor-corrected, multi-stage charging in an ultra-compact, small footprint design.

Features:

• Auto ranging universal input voltage (90 - 265V AC, 47 - 63 Hz) can be used in most parts of the world
• Can be mounted in a variety of positions
• Microprocessor-controlled, multistage charging algorithms
• Settings for two and three-stage charging
• Charges flooded, gel, AGM or lead-calcium batteries
• Temperature-compensated charging
• Power factor corrected for efficient charging
• Ability to charge healthy batteries drained to low voltage
• Easy access to AC and DC wiring from one side
• Reverse battery polarity protection
• Over and under-temperature protection
• DC over-voltage and battery overcharging protection
• Drip-proof design
• Tested to conform to ingress protection rating IP32 and meets UL1564, UL1236 including marine supplement and ABYC standards

Note: This charger replaces the first-generation TrueCharge 10TB unit

Specifications:

• Battery Banks: 2
• Maximum Amperage per Bank:
  • Distributed battery technology can deliver 100% of available amps to any one bank if needed
• Stages:
  • Bulk
  • Absorption
  • Float

Data Sheet
